Lumbosacral transitional vertebra

see http://www.ajnr.org/content/31/10/1778

Lumbosacral Transitional Vertebra LSTVs is a congenital spinal anomaly defined as either sacralization of the lowest lumbar segment or lumbarization of the most superior sacral segment of the spine.

It has been considered as one of the reasons for back pain.

Epidemiology

LSTVs are common in the general population, with a reported prevalence of 4%–30% 1) 2) 3) 4) 5) 6) 7) 8) 9) 10) 11) 12) 13) 14).

The conus medullaris (CM) level, when lumbarization occurred, was lower, with a mean level at L1-L2, whereas a more superior mean level at T12-L1 was seen when sacralization occurred. CM level was not influenced by sex, age, or pathology other than tethered cords 15).

Case series

Four hundred ninety-four LSTV patients were included and categorized into sacralization (n = 201) or lumbarization groups (n = 293). Magnetic resonance imaging (MRI) of all of the LSTV patients were reviewed to determine the level of dural sac (DS) termination, the shortest distance between the apex of the sacral hiatus and DS, and the presence and the caudal level of sacral perineural cysts. Each lumbosacral vertebra column was divided into 3 equal portions (upper, middle, and lower thirds). The MRI findings in both of the groups were compared and analyzed.

The distribution frequency of the levels of DS termination demonstrated a significant difference between the 2 groups. The mean caudal DS level in the lumbarization group was significantly lower than the sacralization group (lower third of the S2 [131 {44.7%} of 293 patients] vs. lower third of the S1 [78 {38.8%} of 201 patients]). The DS terminated at the S3 in more than 19% of the lumbarization group, whereas in only one case of the sacralization group. Although the incidence of perineural cysts was not significantly different between the 2 groups, the mean level of caudal margin of perineural cysts in the lumbarization group was significantly lower than the sacralization group (middle third of the S3 [10 {35.7%} of 28 cases] vs. middle third of the S2 [11 {44%} of 25 cases]).

This study reveals several limitations including the practical challenge of accurate enumeration of the transitional segment and the constraints on generalizability posed by the single-country study.

When planning CEB for patients with LSTV, pre-procedural MRI to check the anatomical structures, including the level of DS termination and caudal margin of perineural cysts, would be of great use for lowering the risk of unexpected dural puncture during the procedure, especially in the lumbarization cases 16).

1)
Bron JL, van Royen BJ, Wuisman PI. The clinical significance of lumbosacral transitional anomalies. Acta Orthop Belg 2007;73:687–95
2)
Castellvi AE, Goldstein LA, Chan DP. Lumbosacral transitional vertebrae and their relationship with lumbar extradural defects. Spine 1984;9:493–95 ((Chang HS, Nakagawa H. Altered function of lumbar nerve roots in patients with transitional lumbosacral vertebrae. Spine 2004;29:1632–35
3)
Delport EG, Cucuzzella TR, Kim N, et al. Lumbosacral transitional vertebrae: incidence in a consecutive patient series. Pain Physician 2006;9:53–56
4)
Elster AD. Bertolotti's syndrome revisited: transitional vertebrae of the lumbar spine. Spine 1989;14:1373–77
5)
Hahn PY, Strobel JJ, Hahn FJ. Verification of lumbosacral segments on MR images: identification of transitional vertebrae. Radiology 1992;182:580–81
6)
Hughes RJ, Saifuddin A. Imaging of lumbosacral transitional vertebrae. Clin Radiol 2004;59:984–91
7)
Luoma K, Vehmas T, Raininko R, et al. Lumbosacral transitional vertebra: relation to disc degeneration and low back pain. Spine 2004;29:200–05
8)
Taskaynatan MA, Izci Y, Ozgul A, et al. Clinical significance of congenital lumbosacral malformations in young male population with prolonged low back pain. Spine 2005;30:E210–13
9)
Tini PG, Wieser C, Zinn WM. The transitional vertebra of the lumbosacral spine: its radiological classification, incidence, prevalence, and clinical significance. Rheumatol Rehabil 1977;16:180–85
10)
O'Driscoll CM, Irwin A, Saifuddin A. Variations in morphology of the lumbosacral junction on sagittal MRI: correlation with plain radiography. Skeletal Radiol 1996;25:225–30
11)
Otani K, Konno S, Kikuchi S. Lumbosacral transitional vertebrae and nerve-root symptoms. J Bone Joint Surg Br 2001;83-B:1137–40
12)
Peh WC, Siu TH, Chan JH. Determining the lumbar vertebral segments on magnetic resonance imaging. Spine 1999;24:1852–55
13)
Seçer M, Muradov JM, Dalgiç A. Evaluation of congenital lumbosacral malformations and neurological findings in patients with low back pain. Turk Neurosurg 2009;19:145–48
14)
Wigh RE, Anthony HF Jr.. Transitional lumbosacral discs: probability of herniation. Spine 1981;6:168–71
15)
Kershenovich A, Macias OM, Syed F, Davenport C, Moore GJ, Lock JH. Conus Medullaris Level in Vertebral Columns With Lumbosacral Transitional Vertebra. Neurosurgery. 2016 Jan;78(1):62-70. doi: 10.1227/NEU.0000000000001001. PubMed PMID: 26348013.
16)
Jeon JY, Jeong YM, Lee SW, Kim JH, Choi HY, Ahn Y. The Termination Level of the Dural Sac Relevant to Caudal Epidural Block in Lumbosacral Transitional Vertebrae: A Comparison between Sacralization and Lumbarization Groups. Pain Physician. 2018 Jan;21(1):73-82. PubMed PMID: 29357336.
