Atlanto-axial subluxation (AAS) is a disorder of C1-C2 causing impairment in rotation of the neck. The anterior facet of C1 is fixed on the facet of C2. It may be associated with dislocation of the lateral mass of C1 on C2.

Atlantoaxial instability (AAI) is characterized by excessive movement at the junction between the atlas (C1) and axis (C2) as a result of either a bony or ligament abnormality.

Atlantoaxial instability with and without basilar invagination poses a considerable challenge in management regarding reduction, surgical approach, decompression, instrumentation choice, and extent of fusion. A variety of strategies have been described to reduce and stabilize cranial settling with basilar invagination.

Atlantoaxial dislocation (AAD) is the most common bony craniovertebral junction (CVJ) anomaly followed by basilar invagination (BI) and assimilation of the atlas.

Atlantoaxial dislocation in children is a very rare condition.

Antero-posterior subluxation

Atlantoaxial rotatory subluxation.

The Fielding classification is commonly used to categorize atlanto-axial subluxation based on the degree of displacement and the associated neurological or ligamentous damage. This classification system is primarily used to assess subluxations that occur due to trauma or inflammatory diseases, particularly in cases of rheumatoid arthritis or other conditions that lead to instability in the cervical spine.

Fielding Classification for Atlanto-Axial Subluxation

The etiology and pathological morphology of atlantoaxial dislocation (AAD) are complex. Based on the pathological anatomical characteristics of AAD, combined with clinical techniques, it is essential to formulate reasonable classification criteria and develop corresponding treatment strategies for different types of AAD. The satisfactory outcome of surgical treatment for AAD can only be achieved through the comprehensive application of various atlantoaxial reduction techniques, tension band releasing techniques, internal fixation, and fusion techniques. This article discusses the latest advancements in surgical treatment techniques for AAD, thoroughly explores treatment strategies based on different types of AAD, and analyzes the practicality and effectiveness of clinical classification and treatment strategies. The posterior atlantoaxial facet releasing and distraction compression reduction technique may pose challenges to traditional treatment strategies in the future. In the development of surgical treatment techniques for AAD, micro spinal surgical techniques may play a significant role in improving surgical methods and enhancing treatment outcomes ¹⁾.

Atlanto-axial subluxation etiology.

see Atlanto-axial subluxation in rheumatoid arthritis.

As a manifestation of ankylosing spondylitis (juvenile and adult onset), reactive arthritis, juvenile idiopathic arthritis.

Craniocervical malformation

Congenital os odontoideum

Odontoid fracture

Disruption of transverse ligament

Atlantoaxial fracture

Chiari malformation and herniation of the cerebellar tonsils into the foramen magnum appears to the natural protective phenomenon in the face of atlantoaxial instability ²⁾.

Upper cervical spinal epidural abscess (UCEA) (occiput to C2) is an uncommon condition. In upper cervical spine infections, degradation of the odontoid ligaments with subsequent Atlanto-axial subluxation or dislocation is a risk.

Neurologic symptoms occur when the spinal cord is involved.

AAD commonly present with progressive neurologic deficits due to compression of high cervical cord, lower brainstem and lower cranial nerves. Less commonly patient's with AAD may also present with neurologic symptoms attributable to vascular compromise at the CVJ ³⁾.

Distance between the anterior surface of the dens and the posterior surface of the tubercle of C1 is usually 3 mm or less in adults and 5 mm or less in children This space is called by many names: predentate space, predental space, atlantodental distance.

The distance may increase slightly on flexion in children but is usually unchanged between flexion and extension in adults

Forward movement of the atlas on the axis is normally restricted by the transverse ligament.

Atlantoaxial instability is defined by an increase in the predentate space of greater then 3 mm in adults and 5 mm in children

Plain film (C spine)

In a non traumatic setting flexion and extension views may be performed. The expected distance between anterior arch of C1 and the dens in the fully flexed position should be <3 mm in an adult (~5 mm in a child).

In a vertical subluxation the dens is often above the McGregor line by over 8 mm in men and 9.7 mm in women

On CT, C1 is not oriented in line with the head. The head may be pointed anteriorly, C1 is turned. If this is a fixed defect, C2 is rotated in conjunction with C1.

Congenital

os odontoideum

Down syndrome (20%)

Morquio syndrome

spondyloepiphyseal dysplasia

Osteogenesis imperfecta

Marfan disease

neurofibromatosis type 1 (NF1)

Arthritides

rheumatoid arthritis

psoriatic arthritis

Reiter syndrome (reactive arthritis)

ankylosing spondylitis

systemic lupus erythematosus (SLE)

Acquired

trauma

retropharyngeal abscess/Grisel syndrome

Atlanto-axial rotatory subluxation.

Odontoid fracture.

Atlanto-axial subluxation in Down syndrome

Atlanto-axial Subluxation Treatment.

Posterior atlantoaxial dislocation (AAD) is rare and mostly follows trauma to the craniovertebral junction (CVJ).

Biomechanics include a significant force with severe hyperextension and cranial traction at CVJ. This is known to be associated with extensive facial injuries ^{4) 5)}.

Traumatic posterior atlantoaxial dislocation without fracture of odontoid process usually presents without a severe neurological deficit. Even if it presents with mild or transient neurological deficit, it would be restored without any residual deficits. Closed reduction is usually successful and safe. The need for fusion after successful closed reduction depends on the integrity of the transverse ligament and the stability of cervical spine. If anatomic reduction is not achieved by closed reduction, open reduction and fusion should be performed.

see Atlanto-axial subluxation case series.

Atlanto-axial subluxation case reports.

Atlanto-axial subluxation with a predominant right-sided component (difficulty in right rotation), accompanied by wedging of the right posterior lateral mass of C1 and tearing of the odontoid process, which has migrated with the anterior arch of C1, causing secondary compression of the posterior arch of the atlas in the vertebral canal.

It is challenging to reduce.

C1-C2 wiring involves significant technical difficulty with a higher risk of myelopathy.
